Stretch wrapping machines are used to wrap stretch film around a loaded pallet. Film provides extra support while the products are being transported & storaged to protect them from tip, spill or from being damaged. Additionally , wrapped loads can easily be separated and identified. Stretch pallet wrapper is widely used in chemical industry electronic industry building materials home appliances papermaking foodstuff & drink etc
Automatic Stetch Wrapping Machine |
Stetch Wrapping Machine |
|
MFC-00A Automatic stetch wrapping machine with Remote Controlled |
|
|
Size of the product to be wrapped |
|
|
Min load size(L XWxH) |
500 X 500 X 500 mm |
|
Max load size(LXW) |
1200 X 1200 mm , or custom made |
|
Max load height |
2100mm (Option: 2500mm, 3000mm) |
|
Max weight |
2000kgs (Option: 3000kgs) |
|
Film Carriage |
|
|
Carriage |
Power pre-stretch film carriage, stretch ratio up to 300% Carriage door opens for effortless roll change and thread film Film tension adjustable |
|
Machine Specification |
|
|
Turntable rotation speed: |
3-15 rpm adjustable |
|
Turntable diameter |
1800mm / 2000mm |
|
Loading weight |
2000kg / 3500kg |
|
Carriage Up/down speed |
0 – 5.5 meters/min adjustable |
|
Power supply voltage |
3PH 380VAC or 440VAC |
|
Power |
2.5Kw |
|
Packing efficiency |
25 – 35 loads/hour |
|
Forklifting |
Front & Rear |
|
Stretch Film Roll detail |
|
|
Max. external diameter (D): |
230 mm |
|
Internal diameter (d): |
76 mm |
|
Film roll height (h): |
500 mm |
|
Film thickness: |
17-35 µm |
|
Standard Options |
|
|
Pneumatic top platen |
|
|
Machine color |
|
|
Turntable diameter: 1800mm, 2000mm |
|
|
Weight Capacity:3500kgs |
|
|
Packing height: 2500mm ; 3000mm |
|
